SDI DVR & Combo


Technical Parameters
Shape Dimension
Similar Products
Annex Download


 Features:  · 16CH HD-SDI video 1080P realtime preview
 · H.264 dual-stream video compression
 · Max 100fps(PAL)120fps(NTSC)@720P
 · HDMI / VGA simultaneous video output
 · 16 channel synchronous 720P realtime playback,
   GRID interface & smart search
 · Support 2 SATA(1 SATA&1 e-SATA) HDD, 2 USB2.0
 · Multiple network monitoring: Web viewer, CMS,P2P.
   Smart Phone App(iPhone/Android/Windows)
Specification:
  Model No.: ST-SDVR1672W
System Compression Format H.264
OS Embedded Linux
Video Input 16CH(SDI/BNC)
  Standard Output 1*VGA:1080P(1920X1080),HDMI:1080P(1920X1080)
Audio Audio Input 1
Audio Output 1
Recording 720P 100fps(PAL)120fps(NTSC)
Recording Mode Schedule, Manual,  Motion,Alarm
Playback Playback Channel 16CH
Search  Mode Time, Event, File Management,
Backup USB Disk 2 USB2.0 interface
DVD Burner NA
Back up Format DAT or AVI
Remote Application Dual Stream Master stream: 1CH   Network stream: 1~25/30fps@CIF
Browser IE (Windows XP/2000/Vista/7)
CMS YES
3G NA
User Access 10 users online with professional authority management
Alarm Alarm Input NA
Alarm Output NA
Storage HDD 2 SATA
PTZ PTZ Extenable
Network Ethernet 1,000 Mbps Ethernet (RJ-45)
Protocol TCP/IP, DHCP, DDNS, NTP, SMTP,RTSP,ONVIF,RTMP,FTP
Max. User Access 10 users
Others IR Controller NA
Power Supply DC12V
Operating Temperature -10~50
Humidity 10% ~ 90% Humidity
