SDI DVR & Combo


Technical Parameters
Shape Dimension
Similar Products
Annex Download


 Features:  · 4CH HD-SDI video 1080P realtime live view
 · H.264 dual-stream video compression
 · Max 100fps(PAL)120fps(NTSC)@1080P
 · HDMI / VGA simultaneous video output
 · 4 channel synchronous realtime playback,
   GRID interface & smart search
 · Support 2 SATA(1 SATA&1 e-SATA) HDD, 2 USB2.0
 · Multiple network monitoring: Web viewer, CMS,P2P,
   Smart Phone App(iPhone/Android/Windows)
Specification:
  Model No.: ST-SDVR0482W
System Compression Format H.264
OS Embedded Linux
Video Input 4CH(SDI/BNC)
  Standard Output 1*VGA:1080P(1920X1080),HDMI:1080P(1920X1080)
Audio Audio Input 1
Audio Output 1
Recording 1080P 100fps(PAL)120fps(NTSC)
Recording Mode Schedule, Manual,  Motion
Playback Playback Channel 4CH
Search  Mode Time, Event, File Management, Image(snapshot)
Backup USB Disk 2 USB2.0 port
DVD Burner NA
Back up Format DAT or AVI
Remote Application Dual Stream Master stream: 1CH   Network stream: 1~25/30fps@CIF
Browser IE (Windows XP/2000/Vista/7)
CMS YES
3G NA
User Access 10 users online with professional authority management
Alarm Alarm Input NA
Alarm Output NA
Storage HDD 1SATA
PTZ PTZ NA
Network Ethernet 1,000 Mbps Ethernet (RJ-45)
Protocol TCP/IP, DHCP, DDNS, NTP, SMTP,RTSP,ONVIF,RTMP,FTP
Max. User Access 10 users
Others IR Controller NA
Power Supply DC12V
Operating Temperature -10~50
Humidity 10% ~ 90% Humidity
